This 90° Elbow Plastic Hose Connector is a precision-molded industrial component designed for secure, leak-proof fluid transfer in plumbing, automotive, and machinery systems. Featuring a right-angle design with flexible ribbed corrugations, this connector accommodates installation in tight spaces while providing excellent flexibility and pressure resistance. It serves as a critical link between hoses, pipes, and equipment, ensuring reliable performance in both static and low-vibration applications.
Basic Information
Item | Specification |
Product Type | 90° Elbow Plastic Hose Connector (Right-Angle Adapter) |
Core Materials | PP (Polypropylene), PA66 (Nylon 66), PE (Polyethylene) |
Connection Type | Push-Fit (Ribbed Insert for Hose/Pipe) |
Bend Angle | 90° (Right Angle) |
Operating Temperature | -40°C ~ 120° C (varies by material) |
Working Pressure | Up to 1.6 MPa (16 bar) (depending on material and size) |
Color | Black (Standard), White, Grey (Custom Available) |
Size Range | Customizable for Hose Inner Diameter (ID) 10mm ~ 50mm |
Certifications | ISO 9001, FDA (Food-Grade), RoHS, REACH |
Core Functions | Fluid Transfer, Directional Change, Flexibility, Leak-Proof Sealing |
Performance
Superior Sealing & Leak-Proof Performance
The integrated ribbed structure creates a tight friction fit with hoses, preventing leakage and ensuring stable fluid flow. The elbow design maintains directional flow without sharp bends that cause pressure drops.
Excellent Flexibility & Installation Versatility
The corrugated flexible section allows for slight movement, accommodating installation in tight spaces and reducing stress on hose connections. The 90° angle simplifies corner routing in complex systems.
High Mechanical Stability
Rigid plastic construction resists deformation under pressure, while the reinforced material options provide high tensile strength and load-bearing capabilities, ensuring long-term reliability.
Wide Temperature & Chemical Resistance
Temperature Range: Works reliably from -40°C to 120°C (varies by material grade).
Chemical Compatibility: Resists water, mild acids, alkalis, and common industrial fluids (PP/PA66 grades); select grades resist oils and fuels.
Durability & Long Service Life
Resists aging, UV radiation, and corrosion, outperforming standard rubber connectors in harsh industrial environments. Low maintenance requirements reduce operational costs.
Easy Assembly & Disassembly
Tool-free push-fit design allows for quick installation without additional adhesives or clamps, saving time on-site. The smooth inner surface minimizes flow resistance and debris buildup.
Application
Automotive Industry: Connects coolant hoses, brake fluid lines, and air intake systems in vehicles and heavy machinery.
Plumbing & Sanitation: Joins water supply lines, drain pipes, and irrigation systems in residential, commercial, and industrial buildings.
Electrical Equip ment: Protects and routes wiring harnesses in control panels and machinery (insulating grade).
Food & Beverage Processing: Transfers liquids and semi-solids in food processing lines (FDA-compliant PP/PE grades).
Medical Devices: Connects fluid lines in diagnostic and treatment equipment (biocompatible PA66 grades).
Agricultural Machinery: Irrigation system connections and sprayer line couplings.
